AL Armoured Low Voltage XLPE PVC Power Cable Factory Direct
AL Armoured Low Voltage XLPE PVC Power Cable Factory Direct
Aluminum armoured power cable with XLPE insulation and PVC sheath, low voltage cable for industrial and building power distribution.
This low voltage power cable adopts aluminum conductor, equipped with XLPE insulation, metal armor layer and PVC outer sheath.
XLPE insulation features high temperature resistance and reliable insulating performance. Built-in armor layer can resist impact, extrusion and rodent bite, perfect for direct burial. Outer PVC sheath provides great anti-corrosion and anti-aging performance. Multiple core sizes are optional, widely used for underground, pipeline and indoor laying of residential, commercial and industrial power supply projects.
Product Advantages
Light aluminum conductor reduces overall weight and construction cost.
Armored structure provides strong mechanical protection for buried installation.
Heat-resistant XLPE insulation increases cable current carrying capacity.
PVC outer sheath resists moisture, chemical and outdoor weather erosion.
Complete core specifications fit various low voltage power load demands.
Application Scenarios
Buried power distribution lines for residential areas and industrial parks.
Main power transmission cables of malls, offices and factories.
Low voltage power wiring for schools, hospitals and infrastructure.
Power circuit renovation and new construction engineering projects.
Quality & Service Support
All aluminum armored cables pass insulation and tensile tests before delivery. Factory direct wholesale for bulk orders. View full technical parameters at https://yidongjiaolian.com
| Item | Specification |
|---|---|
| Model | YJLV (Non-armored) / YJLV22 (Steel Tape Armored) |
| Conductor | Aluminum Stranded Core |
| Core Number | 1/2/3/3+1/3+2/4/4+1/5 Core |
| Cross Section | 1.5–630mm² |
| Rated Voltage | 0.6/1kV, 8.7/10kV |
| Insulation | XLPE (Cross-linked Polyethylene) |
| Outer Sheath | PVC |
| Long-term Temp | -40℃ ~ 90℃ |
| Short-circuit Max Temp | 250℃ (≤5s) |
| Min Bending Radius | Single core ≥20D; Multi-core ≥15D |
| Executive Standard | GB/T12706.1-2020, GB/T12706.3-2020 |
| Application | Indoor, Cable Trench, Direct Buried Fixed Wiring |
| Certificate | ISO9001, CCC, CE |
| Service Life | 30+ Years |
